Notta lotta ' technical drawings ' for these suckers . I think youll find whats there here spot on .







Was done twice . So theres TWO . Spot the differance .    ( We'll Wait .  )




https://ww2aircraft.net/forum/threads/hawker-typhoon-and-tempest-with-rr-griffon.59694/

The Sabre version theres a few about . but notta lot .


clicking on the pictures , getsem way clearer . https://oldmachinepress.com/2020/09/20/napier-h-24-sabre-aircraft-engine/

" The first prototype (LA610) made its initial Sabre VII-powered flight on 3 April 1946. This aircraft would go on to record a speed of 483 mph (777 km/h) at 18,500 ft (5,639 m) and 422 mph (679 km/h) at sea level.  "



Strewth . theres a SECOND picture of it . NOW.




https://oldmachinepress.com/2020/09/20/napier-h-24-sabre-aircraft-engine/  from , click on pictures .






Tempest ONE is similar H Wt. in retrospect . Fury is l. Wt. Tempest ! ./





and heres the reol one .

https://oldmachinepress.com/2014/10/14/hawker-fury-i-sabre-powered/
